CT Part #

Foster Part #

Weight (lbs)

Weight (kg)

Required

Description

Qty

11-1043	11-1043	0.02 lbs	0.009 kg	16	Hex Head Cap Screw, 3/8" x 1-1/4"
11-113	11-113	0.03 lbs	0.01 kg	2	Allen Head Cap Screw, 3/8" x 1"
11-1132	11-1132	0.01 lbs	0.005 kg	1	Cotter Pin, 1/8" x 1-3/4"
11-1186	11-1186	0.02 lbs	0.009 kg	6	Hi-Pro Key
11-124	11-124	0.02 lbs	0.009 kg	4	Transmission Plate Dowel Pin, 5/16" X 3/4"
11-1492	11-1492	0.20 lbs	0.09 kg	2	Hex Head Capscrew, 1/2" x 2-1/4"
11-176	11-176	0.01 lbs	0.005 kg	2	Hi-Pro Key No. 18
11-196	11-196	0.01 lbs	0.005 kg	10	Lockwasher, 3/8"
11-200	11-200	0.04 lbs	0.02 kg	12	Hex Head Capscrew, 5/16" x 3/4"
11-299	11-299	0.03 lbs	0.01 kg	1	Drain Petcock Fitting
11-321	11-321	0.20 lbs	0.09 kg	2	90-degree Elbow, 1/4" (male to female)
11-349	11-349	0.02 lbs	0.009 kg	1	O-Ring
11-436	11-436	0.05 lbs	0.02 kg	1	90-degree Elbow Fitting, 5/16" Ferrule to 1/8" Pipe (Brass)
11-542	-	0.01 lbs	0.005 kg	1	Allen Set Screw, 3/8" X 1/2"
11-572	11-572	0.05 lbs	0.02 kg	6	Allen Head Cap Screw, 5/16" x 3/4" NF
11-595	11-595	0.01 lbs	0.005 kg	2	Oil Pump Gear Set Screw, 5/16" x 1/2"
11-603	11-603	0.06 lbs	0.03 kg	18	Hex Head Cap Screw, 3/8" x 1-1/4"
11-604	11-604	0.05 lbs	0.02 kg	6	Hex Head Cap Screw, 3/8" x 3/4"
11-662	11-662	0.02 lbs	0.009 kg	20	Hex Head Cap Screw, 5/16" x 1/2"
11-900	11-900	0.01 lbs	0.005 kg	3	Spirolox Ring
119-202	119-202	4.00 lbs	1.81 kg	1	Oil Pump Assembly
50-12-2	50-12-2	10.40 lbs	4.72 kg	1	Low Clutch Gear
50-13-1	50-13-1	18.41 lbs	8.35 kg	1	Clutch Assembly
50-193	50-193	0.60 lbs	0.27 kg	1	Shifting Yoke
50-20	50-20	6.20 lbs	2.81 kg	1	Ring Gear and Pinion
50-28-3	50-28-3	4.40 lbs	1.20 kg	1	Shifting Fork
50-32-1	50-32-1	1.40 lbs	0.64 kg	3	Bearing Assembly (PN 50-32-1A, 50-32-1B)
50-45-1	50-45-1	0.01 lbs	0.005 kg	2	Bearing Spacer
50-83	50-83	0.01 lbs	0.005 kg	1	Ring & Pinion Shim
50-9-1	50-9-1	3.80 lbs	1.72 kg	1	High Clutch Gear
56-81	56-81	0.02 lbs	0.009 kg	1	Oil Sight Gauge
58-10	58-10	4.00 lbs	1.81 kg	1	High Drive Gear
58-137-1	58-137-1	0.06 lbs	0.03 kg	1	Pinion Spacer
58-14-2	58-14-2	8.80 lbs	3.99 kg	1	Clutch Shaft
58-143-1	58-143-1	0.40 lbs	0.18 kg	1	Oil Pump Gear
58-17-3	58-17-3	12.00 lbs	5.44 kg	1	Transmission End Plate
58-23	58-23	3.40 lbs	1.54 kg	1	Bottom Bearing Cap
58-23-1	58-23-1	3.20 lbs	1.45 kg	1	Top Bearing Cap with Hole
58-25	58-25	0.33 lbs	0.15 kg	4	Bearing
58-255	58-255	0.01 lbs	0.005 kg	1	Transmission End Plate Gasket
58-261	58-261	0.01 lbs	0.005 kg	3	Bearing Cap Gasket
58-27-10	58-27-10	8.20 lbs	3.72 kg	1	Clutch Lever with Shaft
58-29-1	58-29-1	3.40 lbs	1.54 kg	1	Back Bearing Cap
58-295	58-295	1.40 lbs	0.64 kg	2	Side Cover Plate
58-363-1	58-363-1	0.10 lbs	0.05 kg	1	Castle Nut, 1"
58-366	-	0.03 lbs	0.01 kg	2	O-Ring Gasket
58-37	58-37	0.01 lbs	0.005 kg	1	Motor Gasket
58-400	58-400	0.01 lbs	0.005 kg	1	Gasket Set
71-200	71-200	0.01 lbs	0.005 kg	1	Ring Gear Gasket
77-90	77-90	41.80 lbs	18.96 kg	1	Hydraulic Motor (standard)
77-90-2	77-90-2	43.50 lbs	19.73 kg	1	Hydraulic Motor (high torque)
92-183	92-183	1.00 lbs	0.45 kg	1	Bearing Assembly
92-253-1	-	0.01 lbs	0.005 kg	3	Motor Adapter Gasket (thin)
92-253-2	-	0.01 lbs	0.005 kg	1	Motor Adapter Gasket (thick)
93-11	93-11	5.30 lbs	2.40 kg	1	Drive Shaft
93-114	93-114	0.06 lbs	0.03 kg	1	Oil Pump Discharge Line
93-115	93-115	0.02 lbs	0.009 kg	1	Oil Line
93-125	93-125	176.00 lbs	79.83 kg	1	Counter Balance Assembly
93-166	93-166	0.10 lbs	0.05 kg	14	Hex Head Cap Screw, 3/8" x 1"
93-18	93-18	8.00 lbs	3.63 kg	1	Ring Gear Cover
93-183	93-183	0.50 lbs	0.23 kg	1	Bearing Assembly
93-19	93-19	11.90 lbs	5.40 kg	1	Ring Gear Hub and Sprocket
93-251	93-251	0.01 lbs	0.005 kg	1	Chain Side Cover Plate Gasket
93-295-1	93-295-1	3.70 lbs	1.68 kg	1	Chain Side Cover Plate
93-32	93-32	2.50 lbs	1.13 kg	1	Bearing Assembly
93-37-2	93-37-2	3.20 lbs	1.45 kg	1	Motor Adapter
